News & Case
News & case
  • The development direction of automotive wiring harness
    Aug 29, 2022 The development direction of automotive wiring harness
    The development direction of automotive wiring harness   Competition among wire harness manufacturers has intensified. Product development to a certain period, competitors will also have scale, strength, integrity of the enterprise to compete. Smaller companies will be weeded out. Wiring harness assembly is increasingly concentrated in technologically capable enterprises.     Because the automotive wiring harness is different from the general wiring harness, there are some electronic components attached to the car wiring harness, such as sensors, thick film circuit mixed, such electronic components have high technical content, emphasizing the technical safety and reliability; Has gone beyond simple, generic assembly. It is reported that a mid-range car, there are nearly a thousand interface, more than 30 microprocessors, hundreds of pairs of connectors, the total length of wire used is 1500m-2000m. With the development of IT technology and the emergence of E concept car, put forward the development direction of automobile network, modular, network cluster has been ready to appear, so that the wiring harness manufacturing technology will appear a second leap. The function of wire harness extends from ordinary signal transmission to data transmission.     In addition, the limitations of wire transmission signal, the extensive use of fiber optic cable, automotive wiring harness manufacturing technology for the third leap, cable with transmission speed, large capacity, small volume, strong confidentiality, anti-interference advantages of the good, will soon be a thing of the future automobile data processing and exchange of important material optimization, the power and signal distribution system into a new stage of historical development. Fiber-optic cables are already being used in BMW's D-Class cars, and the Japanese are following suit. The main development trends of wire harness technology are as follows:   1.Multi-channel transmission technology: The technology refers to the transmission of multiple signals over a common media, make the electronic controller can share information, avoids a single connection, the application of this new technology, make the wire connection to simplify, compact structure, can reduce weight, also can reduce the cost, because the information is widely Shared, rather than simply copying, therefore, for fault diagnosis, more accurate, Engineering changes are faster and defects are more easily repaired.   2. Multi-station connection technology: the technology refers to the internal connection system can connect multiple intelligent devices, it can not only share battery energy, reliable grounding, more importantly, it can share data, the technology greatly reduces the input and output of the module, the number of counts, simplify the module and wiring harness assembly; Due to the reduction of a large number of contact points, production cycle, production costs will be s...
    View details
  • Aichie participated in Munich Exhibition, Germany
    May 23, 2022 Aichie participated in Munich Exhibition, Germany
    Electronica China Munich Electronics Show is an exhibition of the electronics industry and an important event in the industry. Over the years, the exhibition has become an innovative platform to lead future electronic technology, incarnating Planet E. The innovation of Planet E helps people to understand more intuitively the driving force behind the development of the electronic world. Aichi Electronics will participate in the exhibition from November 10 to 13, 202211 to witness the development trend of the global electronics industry.
    View details
  • The challenge of wiring harness supply reflects global logistics
    Sep 28, 2022 The challenge of wiring harness supply reflects global logistics
    The challenge of wiring harness supply reflects global logistics     Wiring harnesses became an industry hot spot when the war in Ukraine caused a sudden shortage, but the challenges facing the industry go well beyond the events of 2022.   Due to advanced driver assistance features and the already severe lack of automation and high chip requirements in manufacturing, increasing complexity makes automotive wiring harness production one of the most critical development areas in the industry.   Auto Wire harness     Increasing sensor technology and driver assistance features in cars are making them safer and providing drivers with peace of mind.   Autopilot mode is on the rise in popularity, but even relatively basic cameras to help with parking and infotainment displays can make wiring harps more complex and require more high-speed data cables. Electrification adds extra complexity by introducing battery and brake regeneration management, which means more computing power to make the car as efficient as possible. The more wires and structures are needed, the greater the challenge of supplying the parts and actually making the harness.       Automation Automation in harness manufacturing comes from two sources: the need to make production lines and harness manufacturing processes more efficient, and on the vehicle side, the increasing need for sensors and computers to manage advanced driver assistance systems (ADAS).       Although fully autonomous vehicles are still a long way from production, consumers now expect a variety of driver assistants in their cars. Features such as lidar or other camera technology increase the need for a new data line that must be high-speed enough to provide information in real time.   Companies such as Aptiv are providing the technology for smart cars. Do Sohn, Aptiv's global director of innovation, will speak at the Automotive Wiring Harness Conference in Detroit in October. Also, manufacturers need to look for new technologies, such as fully automatic stranding. Simon Abegg, director of twist machines in Komax's product group, will detail the new robotic process, even for 0.13mm wires. Bob Potock, Zuken's vice president of marketing, will also talk about how digital visualization can help set up wiring harnesses and streamline processes.   Connection     The increasing complexity of wiring harness design, the need for faster cables, and the increasing amount of data being transferred in the car mean that the speed at which data can be moved is important. Frederic Holtzman and Johannes Schmid argue that copper wiring is an essential part of this, not a limitation, and he will show how wiring has been able to reach 100G in automotive wiring harnesses, but the problem lies more in semiconductors. Trying to make the most of lightweight wiring will be key to driving vehicle automation.   Electrification     As the auto ...
    View details
  • Electronica 2022 | Messe Munchen
    Sep 27, 2022 Electronica 2022 | Messe Munchen
    At present, the COVID-19 epidemic has lasted for a long time in the world, and the prevention and control policies are relatively comprehensive. From November 15 to November 18, 2022, Aichie Tech Electronics Co Ltd will participate in the 2022 Electronic Components Show in Munich, Germany.     Founded in 1964, Munich International Electronic Components, Materials and Production Equipment (Electronica) has become one of the largest and most influential electronic components fairs in Europe and the world after more than 50 years of development.   It is reported, electronica 2022 | Messe Munchen is the world's leading electronics trade show and conference exhibitors target groups including the products and services provided by the company for development, quality control, maintenance and repair of electronic components, equipment and machinery. Related Industries: Electrical Engineering, electronics, Retail Trade (distributor), telecommunications, Mechanical engineering, Service provider, Software technology, data processing. As the visitor's target group, developers and designers of application-oriented electronic circuits and products.   That's a good reason for your visit The Electronics Show is the most important international conference venue for the electronics industry. The world's leading trade show covers the entire electronic spectrum from components to systems, applications and services. Extensive conference and support programs highlight automotive, embedded, semiconductor, and wireless and networking startups associated with the industry.   Electronica 2018 in retrospect       Aichie Tech Electronics Co., Ltd. will participate in Electronica 2022 as a merchant, booth number is A2 136; Our company will hold a demonstration there from November 15 to November 18. Visit our booth to learn more about our development in connectors, wires and cables, cable assembly and EV Charger Cable; At that time, we will show our recent and future new products, you can communicate with the CEO at our booth, looking forward to your visit!       A2 136 Electronica 2022 15th - 18th November Munich, Germany   Aichie Tech Electronics Co.,Ltd Email: sales03@aichie.com
    View details
  • Heavy trailer Cable
    Jul 29, 2022 Heavy trailer Cable
      What Gauge Is Trailer Wire?   Aichie Tech Electronic makes trailer cables that are very durable and soft even for cold winter use. Because our sheath thickness is thicker than other factories. So our cables are resistant to friction and can move freely. Our trailer harness is also oil resistant.   The specifications of the trailer cable you choose will depend on the type of trailer and the application of the trailer cable. Suppose you are buying trailer cables for a 7-blade RV connector. In general, for 7-way trailer wire connectors, experts recommend using wire 12AWG for red or black (power) wire, white (ground) wire, and blue (brake power) wire. However, 16 gauge trailer wire is the minimum recommended for the remaining connections, including brown (tail light) wire, yellow (left turn/brake) wire, green (right turn/brake) wire, and purple (reverse light) trailer  cable.   However, if you want to connect different types of applications, your choice of trailer wiring will change. For example, if you have a 8 foot x 35 trailer and you intend to place heavy objects on it, you may need heavier trailer cables to support the application. As a general rule, a project like this usually requires a 16 awg trailer wire. However, if the trailer is longer, you may need a heavier wire gauge - for example, maybe a 14 gauge trailer wire will solve the problem, or maybe even a 12 gauge specification might be called for.   Now turn to slightly different trailer cable application. If you have a 10-foot camper and are working on projects such as license plate lights and wiring of two brake lights, your trailer cable size will be different from the first two applications. In general, if you use LED lights, then a 16awg trailer cable should be fine.   But some types of lights use more power than leds, or your lights may be more than a "typical" trailer. In this case, your choice of trailer cable must also be changed. In this case, a heavy duty trailer cable is recommended. For example, on a 7-way connector, running more lights than usual, or lighting multiple lights at once requires 14/7 trailer wire or even thicker wires, such as 12/7 AWG.   How to install trailer cable?   The general process for installing trailer cables is the same/similar for all applications, regardless of the trailer wire size you use. However, the specifics vary when it comes to the number of connectors involved in trailer wiring.   To correctly install 4-way trailer cable, you can refer to the following wire connection coding:   Ground = White Tail/Running lights = Brown Left turn/Brake = Yellow Right turn/Brake = Green   Note that when using a 4-wire tow line, the left/brake light (yellow) line connector is marked with "L", while the right/brake (green) tow line connector is marked with "R" it.       However, when using a 7-core trailer ...
    View details
  • Aichie-an UL/CUL Listed manufacturer
    May 23, 2022 Aichie-an UL/CUL Listed manufacturer
    AICHIE are a leading manufacturer specializing in Connector and cable assembly Industries. Production facility is located in Dongguan City China, has hundreds of Employees.   We are an UL/CUL Listed manufacturer, has successfully passed ISO9001, ISO13485 quality management system and SGS Certification.   Our products can be exported to all regions of the world, if you have relevant needs, you can contact us, we will give you the best quality service.
    View details
  • What does the busbar of the energy storage cabinet mean?
    Mar 07, 2023 What does the busbar of the energy storage cabinet mean?
    Busbar concept: The busbar refers to the use of a high -electricity copper and aluminum material for transmission of electrical energy and distribution of power capabilities. The total wire of the power station or the transformation station conveyor power can be used. Through it, the electric energy output from the generator, a transformer or a rectifier is transported to each user or other substations.     In the power system, the busbar is connected to each load branch circuit in the power distribution device, which plays a role in gathering, allocating, and transmitting electrical energy. According to the appearance and structure, the bus is roughly divided into the following three categories: 1. Hard busbar: Including rectangular bus, circular busbar, tube -shaped busbar, etc. 2. Soft bus: Including aluminum twisted wires, copper twisted wires, steel core aluminum twisted cables, diameter hollow wires, etc. 3. Close bus: Including the bulk box, the division of the busbar, etc.   Performance characteristics of energy storage cabinet busbar:   The busbar is used in copper or aluminum busbar, with large current density, small resistance, small skin effect, and no need to use. Small voltage reduction means that energy loss is small, and ultimately saving users' investment.   For the cable, because the cable core is multiple copper wires, the root area is larger than that of the busbar of the same current level. And its "skin effect" is serious, reducing the current rated value, increasing the voltage drop, and easy to heat. The energy loss of the wire is great and easy to aging..   Looking at the drawing cabinet drawing, you must first be familiar with the icons of each electrical component, because there are many multiple devices in the power distribution cabinet, and the physical objects and icons of the component can be seen one by one. The role and constituent principle are better, and it is more helpful for the icons. You can search on Google to have a lot of web pages. Bookstores also have books: books such as primary electrical appliances, you can find it.   The installation requirements of the power distribution board (box) are: the power distribution board (box) application is made of non -flammable materials; the production place and office with less dangerous electric shock can be installed with an open power distribution board; Poor processing workshops, casting, forging, heat treatment, boiler room, woodworking room and other places should be installed with closed -type cabinets; in dangerous operating places with conductive dust or produce flammable and explosive gas, they must be installed with closed or explosion -proof type Electric facilities; power distribution boards (boxes) of each electrical component, instrument, switch and cables should be arranged neatly, firm installation, and convenient operation; Generally, 1.2 ~ 1.5m; non -obstacles w...
    View details
  • Smart home wiring harness connection application solution
    Aug 19, 2022 Smart home wiring harness connection application solution
    Smart home wiring harness connection application solution   Home Automation is based on the residential as a platform, using comprehensive wiring technology, network communication technology, security technology, automatic control technology, audio and video technology to integrate the facilities related to home life, to build an efficient management system of residential facilities and family schedule affairs. Enhance home safety, convenience, comfort, art, and achieve environmental protection and energy saving living environment.     Home Automation is the embodiment of iot under the influence of the Internet. Smart home connects all kinds of equipment in the home (such as audio and video equipment, lighting system, curtain control, air conditioning control, security system, digital theater system, video and video server, shadow cabinet system, network home appliances, etc.) through the Internet of things technology. Provide home appliance control, lighting control, telephone remote control, indoor and outdoor remote control, anti-theft alarm, environmental monitoring, HVAC control, infrared forwarding and programmable timing control and other functions and means. Compared with ordinary home, smart home not only has the traditional living function, but also provides construction, network communication, information home appliances, equipment automation, provides a full range of information interaction functions, and even saves money for various energy costs. The concept of smart home originated very early, but there has been no concrete architectural case. It was not until 1984 that the United Technologies Building System It was only when System applied the concept of informationization and integration of building equipment to the CityPlaceBuilding in Hartford, Connecticut, that the first "smart building" appeared. It was the beginning of the world's rush to build smart homes.     Home Automation home automation refers to the use of microprocessing electronic technology to integrate or control electrical and electronic products or systems in the home, such as lighting, coffee ovens, computer equipment, security systems, heating and cooling systems, video and audio systems. Home automation systems mainly use a central microprocessor to receive information from relevant electronic and electrical products (changes in external environmental factors, such as the sun rising or setting light changes, etc.), and then send appropriate information to other electronic and electrical products through established procedures. The microprocessor must control the home's electrical products through a number of interfaces, such as keyboards, touch screens, buttons, computers, telephones, remote controls, etc. The consumer can send signals to, or receive signals from, the central microprocessor.   Home automation is an important system of smart home, in the presence of smart home just, home automation and even equa...
    View details
  • IPC-WHMA-620 Industry Standard
    May 23, 2022 IPC-WHMA-620 Industry Standard
    IPC-WHMA-620 Industry StandardThis is the appearance acceptance standard for cable assembly negotiated by the Cable Assembly Association and the Electronic Connection Products Committee. If there is no standard for process inspection and finished product inspection, IPC/WHMA-A-620 can be used as the inspection standard document for products alone. It specifies process control or defective products that allow repair/rework. This information suggests that it needs to be improved by statistical process control plan (refer to IPC-9191).   Although IPC/WHMA-A-620 is an industry standard, it does not cover all designs. However, it provides process standards for general products. If non-universal or special processes are used, a unique acceptance standard can be established. This unique acceptance standard should include customer requirements or promises, and should include acceptable standards for each feature. If possible, new standards or special standards for products should be submitted to the IPC Committee for standard improvement form, so that the IPC Committee can update the version.
    View details
  • Aichie participation the 2022 Electronic Components Show in Munich, Germany
    Nov 16, 2022 Aichie participation the 2022 Electronic Components Show in Munich, Germany
    On November 15, 2022, the 2022 Electronic Components Show in Munich, Germany. Thousands of manufacturers of electronic components and wiring harnesses from all over the world gathered here.   Aichie Electronics booth is located at Booth A2 136-2 near Gate 5; Once became the focus of the show hall site and exhibitors.   The building style of the show room is cyan green as the main color, through the simple but not simple form to meet the perceptual and rational needs of the space environment, so as to highlight the green products of the company, improve the overall image of the company and Aichie brand.       The products on display are the Aichie company's core products and a series of new products promoted this year. They not only enrich the existing product categories, but also greatly enhance the comprehensive competitiveness of the products. The emerging products, unique workmanship and newly advanced production technology have been praised and recognized by the new and old customers on the site.  Scene of the exhibition:     The main product categories of the exhibition are: 1.Wire & Cables 2.EV Cable Assembly 3.PV Cable Assembly 4.Equipment Cables 5.Molded Cables 6.Battery Cables 7.Electrical Wire Harness 8.Auto Wiring Harness     In this show, all the employees of Aichie Tech Electronics Co.,Ltd actively contributed ideas to the wiring harness show, and all departments actively cooperated and make the effort, which showed the good teamwork spirit of Aichie employees.   We firmly believe that under the leadership of the company leaders, Aichie team in the efforts of the staff, Aichie Tech Electronics Co., Ltd. will hit a new high! Aichie Tech Electronics Co., Ltd. will bring customers better quality products, more efficient service, and more professional wiring harness connect solution!     Congratulations on the success of the Munich Electronic Components Fair! Wish Aichie Tech Electronics Co., Ltd. a bumper harvest in this exhibition show!   A2 136-2 Electronica 2022 15th - 18th November Munich, Germany Aichie Tech Electronics Co.,Ltd   Email: sales03@aichie.com
    View details
1 2 3 4

A total of 4 pages
