MC4 Solar Photovoltaic Panel Wire Connector

  • Item NO.:

    PV-0000-01
  • Order(MOQ):

    100
  • Payment:

    T/T,L/C,Western Union,Paypal,MoneyGram
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Lead Time:

    15 Days
Product Name Solar DC Connector
Model PV-0000-01
Rated Voltage 1000V DC
Rated Current 30A/50A
Temperature Range -40℃~90℃/105℃
Material PC/PPO,Copper
Waterproof IP67
Flame class UL-94-V0
Salt mist spray test,degree of severity IEC 60068-2-52

1set Female Male Solar PV Connector Waterproof IP67

  • 【Product Contents】Comes with 1 pairs solar panel connectors Male & Female + 1 pairs solar connector pins (male & female)
  • 【Compatible Cable】Compatible with PV cables with different insulation diameters (2.5m㎡~6m㎡/AWG14-10).
  • 【Product Features】Operating temperature: -40℉ to 257℉; Rated voltage: 1000V DC; Rated Current: 30A.
  • 【Waterproof & Dustproof】Design with sealing ring for dust resistance and waterproof, degree of waterproof is IP67; Flamebility rating is UL94-V0.
  • 【Premium Material】Made of PPO insulation material, contact material is tin-plated copper. PPO material with excellent aging resistance and UV endurance, can resist severe weather such as heavy rain, snowstorm or heat for a long time.

mc4 solar connector

connector mc4 solar panel connector

Please Contact Aichie,Get the samples!

MC4 Connector

Tel: +86 769 23361430 WeChat: +86 18027502150
WhatsApp: +86 18027502150 Skype: live:.cid.8643b3df38ff8b5
Email: sales03@aichie.com Online Store: www.aichie.en.alibaba.com
Leave A Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Submit
