Best mc4 connectors 1000V 30A Solar Panel Battery Connectors

Solar Connectors - Male & Female IP67 Waterproof Solar Connector:

These connector is specifically designed for connecting photovoltaic solar systems with high mechanical requirements and extreme weather conditions. For permanent installations.

  • Item NO.:

    PV-0000-04
  • Order(MOQ):

    100
  • Payment:

    T/T,L/C,Western Union,Paypal,MoneyGram
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Lead Time:

    15 Days
Product Name Solar DC Connector
Model PV-0000-04
Rated Voltage 1000V DC
Rated Current 30A/50A
Temperature Range -40℃~90℃/105℃
Material PC/PPO,Copper
Waterproof IP67
Flame class UL-94-V0
Salt mist spray test,degree of severity IEC 60068-2-52
  • Solar Connector Conductor pin is tinned Copper: made of PPO + PA material, It makes a rock solid connection after you crimp the pin to the wire, and these are operated perfectly under heavy load. WATERPROOF RING on connection is perfect to seal out water and dust to prevent corrosion, PPO INSULATION MATERIAL with excellent aging resistance and UV endurance, can resist severe weather such as heavy rain,snowstorm or heat for a long time.
  • Solar Connectors Rated voltage - TUV 1000V DC; Rated Current:30A/50A; These solar connectors Hard plastic IP67 Waterproof and resist dust build up.
  • These solar connectors are designed to complete a solar panel (PV) array, typically in parallel applications
  • Fastness of male and female points with stable self-locking system which is easy to lock and open. anti-aging and resistance to ultraviolet radiation.
  • solar connectors compatible with PV cables with different insulation diameters, 1 Sets Solar Connectors ( 1Pcs Male & 1Pcs Female), Suitable for:Solar wire  (2.5m㎡--6m㎡/14AWG - 10AWG)

mc4 panel mount connector

solar panel battery connectors connector solar

FAQ

1. How does your factory control quality?
We are a Medium size factory, more than 15 quality staffs use CKP, PFMEA to manage our production process, we have made a lot of connectors, cables and wire harnesses for Automobiles, Boats and industries. All products are 100% tested before Delivery.

2. Is there any environmental risk on materials?
We are an ISO9001/ISO14001 certificated company, All our materials are RoHS 2.0 compliant, we select materials from big company and always be tested. Our products have exported to Europe and North America for more than 10 years, we can provide COC if needed.

3. How can I customize our products?
If you have drawings please send to us, if no drawings please send us photos or  samples, then tell us your SPEC. For a wire harness we need to know the connector type, wire gauge, wire length and wire diagram.

4. Can you supply OEM & ODM service?
Yes. We have specialized in manufacturing high quality connectors,  cables and wire harnesses for more than 10 years, we have a professional engineering team, OEM & ODM projects are warm welcome.

5. Can you provide samples for testing?
After price confirmation, you can require samples to test performance.Most of samples can be supplied by free ( depends on the kinds and qty),but always need you pay for shipping cost.

6. What is your lead time for mass production?
Honestly, it depends on order quantity and products complexity.
Normal lead time is 3-6 weeks.

7. Any warranties with your products?
We manufacturer long life, durable products for industries, Wire harnesses, always 5 years Warranties, connectors and cables we provide 5-10 years Warranties. This is the longest warranties in our industries, only we can give our customer this promise.

If you want to know more about our products,please contact us now!
