4 to 1 Solar Panel T Branch Connectors Solar Panel Cables and Connectors kit

Solar Cable Connectors for Housing, Commercial Roof, RV TUV Certified

  • Item NO.:

    AC-PV-LT4
  • Order(MOQ):

    100
  • Payment:

    EXW
  • Price:

    $5.22
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Lead Time:

    15 Days
  • Weight:

    180

Wwaterproof type 1 to 4 solar inverter with automatic load connector

Rated Voltage

1000V DC

Rated Impulse Voltage

8000V

Rated Insulation Voltage

6000V

Rated Current

30A

Standard

IEC 62852

Protection Degree

IP67

Contact Resistance

≤0.5mΩ

Pollution Degree

2

Ambient Temperature

-40℃~+85℃

Cable Cross Section Area

2.5mm2,4.0mm2,6.0mm2

Flame Class

UL94-V0





solar cable connectors

Solar connector feature: 1.Terminal with high pure electrolytic copper precision stamping; 2.Safety lock system , can guarantee that the abnormal condition to continue 3.Not in engagement against touch protection design; 4.The part components can be used for the entire system and equipment assembly;

5.In the entire temperature rang (as the derating curves without limitation) of high IP protection (IP67)mc4 plugmc4 parallel connector
